42,000 Max Earth Drill
42,000 Max Earth Drill
Excavators
20 - 45 T (44,100 - 99,200 Lbs)
Pa Series Augers
300mm-1.8m (12 In. - 71 In.) Dia
| MODEL | 42000 MAX |
|---|---|
| Carrier Weight | 20-45t |
| Oil Pressure Range | 180 - 310 Bar |
| Torque Range | 24612 - 42387 Nm |
| Oil Flow Range | 80 - 225 lpm * |
| Speed Range | 9 - 26 rpm |
| Hub Options | 110mm Square |
| Height | 1411 mm |
| Width | 406 mm |
| Weight | 442kg |
| Hitch Options | Single Pin Hitch Double Pin Cradle Hitch PA |
| Auger Range | PA |
| Rec. Drilling Diameter Range | 300 - 1800 mm |
